Stainless Steel Hexaognal Wire Mesh

Stainless Steel Hexaognal Wire Mesh
Stainless Steel Hexaognal Wire Mesh
Stainless Steel Hexaognal Wire Mesh
Stainless Steel Hexaognal Wire Mesh
Stainless Steel Hexaognal Wire Mesh
Stainless Steel Hexaognal Wire Mesh
MESSAGE

Hexagonal wire mesh is firm in structure and has flat surface. If is estensively used in building as reinforcement of the roof and floor. It is also used as fence for poultry cage, fish, garden and children playground.

Material: low carbon steel wire, galvanized wire, stainless steel wire 201,202, 304,304L,316,316L,430

Weaving And Character: normal twisted, reverse twisted and double-way twisted;

Specification: Mesh: 3/8" ,1/2" ,5/8" ,3/4" ,1" ,1-1/4' , 1-1/2" ,2" , 3" , etc.

Wire Diameter: BWG27-BWG14

Width: 10cm-200cm

Length: 20m, 30m, 50m or as client’s requirements.

Specifications:

Hexagonal wire mesh
Mesh size Wire gauge(BWG)
In inch In mm
3/8’’ 10mm 27 26 25 24 23 22 21
1/2’’ 13mm 25 24 23 22 21 20
5/8’’ 16mm 27 26 25 24 23 22
3/4’’ 20mm 25 24 23 22 21 20 19
1’’ 25mm 25 24 23 22 21 20 18
1-1/4’’ 32mm 22 21 20 18
1-1/2’’ 40mm 22 21 20 18 17
2’’ 50mm 22 21 20 18 17 16 15 14
3’’ 75mm 21 20 18 17 16 15 14
4’’ 100mm 17 16 15 14
