Welded Wire Mesh For Construction

Welded Wire Mesh For Construction
Welded Wire Mesh For Construction
Welded Wire Mesh For Construction
Welded Wire Mesh For Construction
Welded Wire Mesh For Construction
Welded Wire Mesh For Construction
Welded Wire Mesh For Construction
Welded Wire Mesh For Construction
MESSAGE


Welded Wire Mesh For Construction (WWR) provides the exact size of reinforcement where needed through variable bar size and spacing, thereby reducing steel waste. Plain Square Mesh sheets are a multi-purpose mesh and complies with AS/NZS 4671 : 2001 Steel reinforcing materials.

  Plain Square Mesh sheets are available in 6 x 2.4 m.

  1.Material: low carbon steel wire,black iron wire, galvanized wire

  2.Wire Diameter: 1.0mm-10mm

  3.Open Size: 25X25mm 50X50mm 55X55mm 50X100mm 50X200mm 100X100mm 150X150mm 100X200mm

  4.size: 3'X6' 4'X8' 1mX2m 1.5mX2.5m 1.8mX2.5m or as client’s requirement

  5.Surface treatment: black, galvanized or pvc coated, pvc color:green,yellow, white,blue

  6.Characteristics: Welding firm, nets hole even, the net surface smooth, corrosion resistance, strength.

  Specifications:


Wire diameter Aperture widthXlength
In inch In mm
1.0mm-3.2mm 1'' 25.4 3'×6'
4'×8''
5'×10''
1m×2m
2.4m×4.8m
As client’s requirements
1.0mm-4.5mm 2'' 50.8
1.6mm-6.0mm 3'' 70.2
1.6mm-6.0mm 4'' 101.6
2.0mm-6.0mm 5'' 127
2.0mm-6.0mm 6'' 152.4
2.0mm-6.0mm 7'' 177.8
2.0mm-6.0mm 8'' 203.2

Packing details:

  Inside the roll with "paper tube" to reduce the pressure while loading; Then wrapped with "plastic film" aswell as the "woven bag" on the finished roll, Final loaded in the strong wooden case or as customers' requirement.
